Cast iron is one of the most historically significant and widely used materials in metalworking. Known for its excellent fluidity, compressive strength, and wear resistance, cast iron plays a vital role in industries ranging from automotive and construction to agriculture and municipal infrastructure. But what exactly is cast iron, and how does it differ from other metals? In this blog, we’ll explore the different types of cast iron, their properties, and how they’re used in modern manufacturing.

What Is Cast Iron?

Cast iron is a group of iron-carbon alloys with a carbon content greater than 2%. Unlike steel, which contains less than 2% carbon, cast iron has a higher carbon content that gives it unique properties such as hardness and brittleness. The carbon in cast iron exists as either graphite or cementite, and the way it forms during solidification is what defines the different types of cast iron.

Cast iron is typically produced by melting pig iron, scrap iron, and other additives in a furnace and pouring the molten metal into molds to create complex shapes. Its excellent castability makes it an ideal material for producing intricate or heavy components that would be difficult to fabricate with steel or other metals.

The Properties of Cast Iron

Cast iron is prized for its mechanical properties, which vary depending on the type and composition. Some of the most important properties include:

  • High Compressive Strength: Cast iron can withstand high loads, making it ideal for structural and load-bearing components.
  • Good Wear Resistance: Its hardness helps resist abrasion and erosion in moving or high-friction parts.
  • Excellent Castability: Cast iron flows easily when molten, allowing for the creation of complex shapes with minimal machining.
  • Dampening Capability: Cast iron absorbs vibrations well, which is why it’s commonly used in machine bases and engine blocks.
  • Brittleness: While strong under compression, cast iron is brittle and may crack under tension or impact, depending on the type.

Types of Iron

There are several main types of cast iron, each with different microstructures and performance characteristics. The most commonly used are:

1. Gray Iron

Gray iron is the most commonly used type of cast iron, named for the gray appearance of its fracture surface due to flake graphite in its microstructure. It offers excellent machinability, good damping capacity, and high compressive strength.

Applications: Engine blocks, brake rotors, pipes, pump housings, and manhole covers.

Grades at QCC: CL-30, CL-35, CL-40, CL-50.

2. Ductile Iron (Nodular Iron)

Ductile iron contains small amounts of magnesium or cerium, which cause the graphite to form in spherical nodules rather than flakes. This structure greatly improves the metal’s ductility and impact resistance, making it more suitable for structural and dynamic applications.

Applications: Automotive suspension parts, gears, heavy equipment components, and pressure-retaining castings.

3. White Iron

White iron contains carbon in the form of cementite, which makes it extremely hard and wear-resistant but also very brittle. It has a white, crystalline fracture surface due to the absence of graphite.

Applications: Liners for cement mixers, slurry pumps, coal crushers, and other abrasive environments.

Grades at QCC: High-chromium ASTM A532 white iron and HC 250.

4. Malleable Iron

Malleable iron is made by heat-treating white iron to convert its carbon into graphite clusters. This process makes the iron more ductile and impact-resistant while retaining good strength.

Applications: Electrical fittings, brackets, and farm equipment parts.

5. Compacted Graphite Iron (CGI)

CGI is a hybrid form of cast iron where the graphite is in a worm-like shape, giving it a balance of strength, thermal conductivity, and fatigue resistance. It’s used increasingly in high-performance applications, especially in engines.

Applications: Diesel engine blocks, cylinder heads, and turbo housings.

Comparing Cast Iron to Other Materials

Compared to steel, cast iron offers better castability and vibration damping, but lower tensile strength and impact resistance. While steel may be preferred for high-tensile loads or weldability, cast iron is more cost-effective for complex parts that don’t require much post-processing.

Compared to non-ferrous metals like aluminum or bronze, cast iron is heavier and harder, but generally less corrosion-resistant. However, alloying and coating options can help mitigate corrosion in many applications.

How Cast Iron Is Used Across Industries

Cast iron’s versatility makes it a valuable material across a wide spectrum of industries:

  • Municipal Infrastructure: Manhole covers, storm grates, and waterworks components rely on cast iron for strength and corrosion resistance.
  • Transportation: Brake rotors, engine blocks, and gear housings in cars and trucks are typically made from gray or ductile iron.
  • Construction and Agriculture: Cast iron is used in structural supports, counterweights, and hydraulic components.
  • Industrial Equipment: Pressure vessels, pumps, valves, bases, and housings benefit from cast iron’s stability and wear resistance.
  • Power Generation: Components for turbines and generators are often cast from high-strength ductile or white iron.

Quaker City Castings and Cast Iron Expertise

At Quaker City Castings, we produce a wide range of cast iron components using advanced no-bake sand casting methods. Our team can deliver gray iron, ductile iron, and high-alloy white iron castings to meet specific customer needs, with in-house pattern making, heat treatment, and machining for full-service delivery.

We maintain strict quality control protocols and offer chemical and mechanical testing to ensure every casting meets the required specifications. Whether you need prototype parts or large-volume runs, our foundry has the equipment and expertise to provide reliable, American-made cast iron castings for demanding applications.

Final Thoughts

Cast iron remains a foundational material in modern manufacturing due to its durability, versatility, and cost-effectiveness. Understanding the different types of cast iron—and their specific benefits—can help engineers and procurement specialists choose the right material for their application.

From gray iron to white iron, and ductile iron to malleable grades, cast iron continues to evolve to meet new challenges in construction, transportation, energy, and infrastructure. At Quaker City Castings, we’re proud to carry on the tradition of high-quality cast iron production here in the United States.

Whether you’re designing a new component or upgrading an existing part, our team is here to help you get the right casting for the job.
